Chevrolet Trax: Body side frame rocker reinforcement replacement

Chevrolet Trax (2013-2022) Workshop Manual / Accessories & Equipment / Collision Repair / Collision repair - Repair instructions / Body side frame rocker reinforcement replacement

Removal Procedure

WARNING: Refer to Approved Equipment for Collision Repair Warning

WARNING: Refer to Glass and Sheet Metal Handling Warning .

NOTE: The body side frame rocker reinforcement is made of Ultra High Strength Dual Phase Steel and should be replaced only at factory joints. Repairing or sectioning of this part is not recommended. Refer to Ultra High Strength Dual Phase Steel.

  1. Disable the SIR system. Refer to SIR Disabling and Enabling .
  2. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection .
  3. Remove all related panels and components.
  4. Repair as much of the damage as possible to factory specifications. Refer to Dimensions - Body (Opel, Encore), Dimensions - Body (Trax).
  5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to Anti- Corrosion Treatment and Repair (Base) .
  6. Locate and mark all the necessary factory welds of the body side frame rocker reinforcement.

Fig. 80: Drilling Factory Welds
Fig. 80: Drilling Factory Welds

  1. Drill all factory welds (1). Note the number and location of welds for installation of the service assembly.

Fig. 81: Body Side Frame Rocker Reinforcement
Fig. 81: Body Side Frame Rocker Reinforcement

  1. Remove the damaged body side frame rocker reinforcement (1).

Installation Procedure

  1. Align the body side frame rocker reinforcement.

Fig. 82: Drilling Plug Weld Holes In Service Part
Fig. 82: Drilling Plug Weld Holes In Service Part

  1. Drill a 8 mm (5/16 in) holes for plug welding along the edges of the quarter outer panel (1) as noted from the original panel.
  2. Clean and prepare the attaching surfaces for welding.

Fig. 83: Body Side Frame Rocker Reinforcement
Fig. 83: Body Side Frame Rocker Reinforcement

  1. Position the body side frame rocker reinforcement on the vehicle (1).
  2. Verify the fit of the body side frame rocker reinforcement.
  3. Clamp the body side frame rocker reinforcement into position

Fig. 84: Plug Welding Body Side Frame Rocker Reinforcement
Fig. 84: Plug Welding Body Side Frame Rocker Reinforcement

  1. Plug the weld accordingly (1).
  2. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to Anti-Corrosion Treatment and Repair (Base) .
  3. Paint the repaired area. Refer to Basecoat/Clearcoat Paint Systems .
  4. Install all related panels and components.
  5. Connect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection .
  6.  Enable the SIR system. Refer to SIR Disabling and Enabling .
