Chevrolet Trax: Roof rear header panel replacement

Chevrolet Trax (2013-2022) Workshop Manual / Accessories & Equipment / Collision Repair / Collision repair - Repair instructions / Roof rear header panel replacement

Removal Procedure

WARNING: Refer to Approved Equipment for Collision Repair Warning .

  1. Disable the SIR system. Refer to SIR Disabling and Enabling .
  2. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection .
  3. Remove all related panels and components.
  4. Repair as much of the damage as possible to factory specifications. Refer to Dimensions - Body (Opel, Encore), Dimensions - Body (Trax).
  5. Remove the sealers and anti-corrosion materials from the repair area. Refer to Anti-Corrosion Treatment and Repair (Base) .
  6. Locate and mark all factory welds.

Fig. 62: Drilling Out Plug Welds
Fig. 62: Drilling Out Plug Welds

  1. Drill all factory welds (1). Note the number and location of welds for installation of the service assembly

Fig. 63: Rear Header Panel
Fig. 63: Rear Header Panel

  1. Remove the damaged rear header panel (1).

Installation Procedure

Fig. 64: Drilling Plug Weld Holes In Service Panel
Fig. 64: Drilling Plug Weld Holes In Service Panel

  1. Drill 8 mm (5/16 in) holes for plug welding along the edges of the service panel (1) as noted from the original panel.
  2. Clean and prepare the attaching surfaces for welding.

Fig. 65: Rear Header Panel
Fig. 65: Rear Header Panel

  1. Position the roof rear header (1) panel on the vehicle.
  2. Verify the fit of the panel.
  3. Clamp the roof rear header panel into position.

Fig. 66: Plug Welding Rear Header Panel
Fig. 66: Plug Welding Rear Header Panel

  1. Plug weld accordingly (1).
  2. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to Anti-Corrosion Treatment and Repair (Base) .
  3. Paint the repaired area. Refer to Basecoat/Clearcoat Paint Systems .
  4.  Install all related panels and components.
  5. Connect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection .
  6. Enable the SIR system. Refer to SIR Disabling and Enabling .
